AMD's Ambitious 20x30 AI Efficiency Goal: Embracing Rack-Scale Architecture and Power Constraints

AMD's 20x30 AI efficiency target hinges on rack scale

Who'd have thunk? The bigger the iron, the more efficient it gets With Moore's Law on its last legs and datacenter power consumption a growing concern, AMD is embarking on an ambitious new goal to boost the energy efficiency of its chips 20-fold before 2030. And it sees rack-scale architectures as a key design point to get there. "The counterintuitive thing here... is the bigger the device, the more efficient it is," AMD SVP and Fellow Sam Naffziger tells El Reg. "But what we're getting is what used to be a whole rack of compute devices in a single package." AMD was among the first to apply this logic to its CPUs and GPUs, embracing a chiplet architecture that enabled it to overcome reticle limits and squeeze more performance from each watt consumed. The ultimate culmination of this philosophy was AMD's MI300 series of APUs and GPUs, which formed a dense sandwich of 3D stacked compute, I/O dies, and interposers. Now, AMD is looking beyond the chip package and even the node to the rack scale to drive efficiencies over the next few years. "That's the way we're going to be able to deliver continued significant improvements is being able to architect almost at the data center level," Naffziger said. AMD isn't the first to reach this conclusion. At GTC last year, Nvidia revealed its first rack-scale system, the GB200 NVL72. Traditionally, both companies' GPU systems have used high-speed interconnects like NVLink or InfiniBand to pool their resources, making four or eight accelerators function as one great big one. With the GB200 NVL72, Nvidia extended this scale-up network to the rack level, using 18 NVLink switch chips to make the 120kW monster's 72 Blackwell GPUs behave as one. This spring, Nvidia unveiled its plans to extend this architecture to 144 and eventually 576 GPUs and up to 600kW of power. However, the idea dates back much further. "Rack scale is really re-inventing the scale-up multi-processing that IBM did in the 80s with shared memory spaces, load and store," but rather than a few dozen System/370 mainframes, we're now talking about tens, potentially hundreds of GPUs, Naffziger contends. AMD's first rack-scale compute platform is slated to arrive next year with the launch of its MI400. Naffziger suggests it'll follow the same basic formula as Nvidia's NVL systems, albeit using the Universal Accelerator Link UALink interconnect rather than NVLink. However, future designs could end up looking quite a bit different. Most notably, Naffziger expects photonic interconnects could replace copper in the scale-up fabrics within the next five years. Co-packaged optics (CPO) have long promised greater bandwidth and reach than copper cables or traces, but have been held back by the increased power consumption associated with the lasers. "Everything's driven by economics, and we're at the point where economics will favor optical," Naffziger said. For all the advantages co-packaged optics presents, it isn't perfect. "There are temperature sensitives with optical," Naffziger said. "There's a lot more to worry about than in electrical space... Now we've got to route fiber attach and make sure it's mechanically robust and not susceptible to vibration." This might explain why Nvidia has focused its early photonics efforts on the scale-out Ethernet and InfiniBand networks rather than boutique chip-to-chip interconnects. Most large scale photonic switches already require extensive use of power-hungry pluggable optics. So, for its first batch of photonic switches, Nvidia is using CPO to eliminate the need for these devices. However, for its NVLink switch fabric, the company appears to be opting for greater rack densities, up to 600kW by 2027, in order to stick to copper. As AMD prepares to scale up, Naffziger notes that process technology and improvements in semiconductor packaging will continue to play a role in achieving its 20x30 goal. "There's still the remnants of Moore's law out there," he said. "We've got to use the latest process nodes." While process technology isn't shrinking as quickly as it once did, there are still improvements to be had -- especially when it comes to memory. Naffziger pointed to 3D stacking and base die customization for high-bandwidth memory (HBM) as potential avenues for driving down the energy per bit, and reducing overall power consumption. HBM accounts for a substantial amount of accelerator power consumption today. You may recall that with the jump from 192GB on the MI300X to 256GB on the MI325X, power consumption increased by 250W. So any packaging technologies that allow for both higher bandwidth and capacity while also curbing power consumption are worth investigating at the very least. Even at rack scale, Naffziger says the "biggest improvements are going to be the fruit of hardware-software co-design. The raw hardware gains are reaching diminishing returns." AMD has trailed in software, particularly when it comes to low-level development. However the situation has improved considerably in the year and a half since its MI300X made its debut. The chip shop has invested considerable resources to optimize its ROCm software stack for a wide range of popular inference and training platforms, including vLLM, SGLang, and PyTorch. These efforts have been bolstered by several acquisitions, including Nod.ai, Mipsology, and Brium. AMD has also been eager to attract AI talent. Most recently, Sharon Zhou, CEO of AMD-friendly startup Lamini, which helps companies tune LLMs to reduce hallucinations, announced her plans to join the House of Zen's AI software efforts on Wednesday. "When we talk about a rack-scale goal, there definitely are big opportunities in system architecture, system design, improved components, integration reducing the cost of communication," Naffziger said. "But we've got to map the workload optimally on that hardware." FP8 and now FP4 support is just one example of this. On the model side, these lower precision datatypes offer a number of advantages, trading often imperceptibly lower output quality for a smaller memory footprint. Meanwhile, halving the precision usually doubles the floating point output of an accelerator. However, it can take software time to catch up to these new data types. It took the better part of a year from the time the MI300X launched to when the popular vLLM inference engine extended hardware support for AMD's FP8 implementation. Software may be key to unlocking the full potential of AMD's silicon, but it also presents challenges when it comes to measuring performance, particularly when it comes to AI workloads. The AI ecosystem is moving incredibly quickly. In a matter of months, a model can go from bleeding edge to antiquated. "We can't assume Llama 405B is going to be here in 2030 and have any meaning," Naffziger said. So for AMD's 20x30 goal, it'll use a combination of GPU FLOPS, HBM, and network bandwidth, which are weighted differently for inference and training to keep track of its progress. ®

AMD CTO: power constraints, not compute, will shape tomorrow's supercomputers

In a nutshell: In his keynote at ISC 2025, AMD CTO Mark Papermaster emphasized that the next wave of supercomputers will demand breakthroughs in efficiency, reliability, and adaptability, not just raw performance. He noted that industry leaders are now grappling with the realities of explosive growth and the increasingly complex challenges it brings. Papermaster began by highlighting the continued surge in demand for high-performance computing, driven primarily by artificial intelligence. He pointed to the emergence of new systems in Germany - such as Jupiter and Blue Lion - as evidence of the sector's rapid expansion. "The performance of supercomputers will continue to increase rapidly," he said, emphasizing that it is user demand that fuels innovation and progress. While AI remains at the forefront, Papermaster stressed that traditional computing techniques are still essential, especially in scientific applications where precision is critical. He explained that double-precision (FP64) calculations remain vital, and although lower-precision formats like FP16 and FP8 are becoming more popular for certain workloads, a hybrid approach is necessary. "It's not just FLOPS!" he said, underscoring that raw compute power is only part of the equation. The conversation soon turned to the practical challenges facing the industry. Papermaster noted that while computational performance can, in theory, scale rapidly, real-world constraints such as bandwidth and power consumption are becoming increasingly critical. He warned that the total board power of accelerators is projected to reach 1,600 watts or more by 2026 or 2027, with 2,000 watts potentially on the horizon. "Power and cooling will be, and in some cases already are, the biggest limitations," he said, adding that memory bandwidth must double every two years to keep pace, which only compounds power demands. Papermaster noted that future AI data centers could consume power on the scale of hundreds of megawatts. He even joked about the possibility of "15 manufacturers of small nuclear reactors," a tongue-in-cheek reference to the industry's surging energy demands. On the product front, Papermaster highlighted AMD's growing momentum with its Instinct accelerators. The MI300X and MI300A have already gained traction, generating $5 billion in their first year and capturing five percent of the market. Looking ahead, he confirmed the upcoming launch of the MI355X, which will offer up to 35 times the inference performance of its predecessor in certain workloads. The new accelerator will be available in both air- and water-cooled variants, underscoring AMD's continued focus on performance and efficiency. Papermaster also touched on the potential of in-memory computing as a future leap in energy efficiency, confirming that AMD is actively exploring the technology. Cost remains a critical concern for professional users, Papermaster acknowledged, as organizations must weigh the trade-off between significant upfront investment and the ongoing expense of extended system runtimes. While AMD continues to support open-source and freely available tools, he admitted that development of their new 2nm chip was "not open - and extremely expensive," requiring significantly more time and resources than previous designs. Many of the tools needed for such advanced chips are proprietary and will likely remain so for the foreseeable future. On the topic of connectivity, Papermaster pointed to "Ultra Ethernet" as a promising technology that could help lower infrastructure costs. He noted that Nvidia, feeling the competitive pressure, has begun opening up its NVLink interconnect to other vendors in response - an effort to counter Ultra Ethernet's disruptive potential. A wider array of options in this space, he suggested, could ultimately help drive down costs and foster a more competitive ecosystem. When asked about the role of RISC-V, Papermaster clarified that while AMD is already using RISC-V in certain applications, it is "currently unrealistic to classify these chips as supercomputers." He emphasized that RISC-V remains in its early stages of maturity and will require substantial development before it can compete at the highest performance tiers. Looking ahead, Papermaster envisioned the ideal supercomputer as a highly versatile system capable of handling a broad spectrum of workloads. He acknowledged that this goal remains a long-term aspiration, and that specialized architectures will continue to dominate for the foreseeable future. However, modular construction - exemplified by projects like Jupiter - provides a promising path forward. Future supercomputers are likely to be assembled from many interconnected components, each optimized for specific tasks. Achieving high performance across such diverse workloads, he said, will require a blend of emerging technologies, including optical interconnects and eventual support for quantum computing.
